Sphere:

-29.00~+26.75 D(step:0.12D/0.25D/0.5D/1D/2D/3D)

Cylinder:

0.00~8.75D (step:0.25D/0.5D/1D/2D/3D)

Cylinder axis :

0~180°(step : 1/5/15/30/45°)

PD:

Far : 48~80mm  Near : 45~75mm  (step:0.5/1.0mm)

Working distance:

35~70cm  (step: 5 cm )

Prism:

0~20Δ(step 0.1Δ/0.2Δ/0.5Δ/1Δ/2Δ)

Jackson cross cylinder:

Jackson cross cylinder 0.25D Jackson cross cylinder 0.50D

Dual cross cylinder (separation prism)

Ophthalmoscope:

+1.5D,+2.0D( measuring distance 67cm, 50cm )

Size and weight

Body of main engine:

362(W)×83(D)×299(H)mm , 3.5kg

Keyboard:

215(W)×230(D)×226(H)mm , 1.5kg

Junction box:

266(W)×72(D)×240(H)mm, 1.3kg

Package size：

600(W)×440(D)×600(H)mm

Voltage:

AC 100~240V, 50/60Hz

Power:

90VA

Auxiliary lens

Pinhole lens:

Φ1mm

Maddox；

Right eye (horizon),left eye (vertical)

Red and green lens：

Right eye(red) , left eye (green)

Polaroid：

Right eye(135°, 45°), left eye (45°, 135°)

Separation prism：

Right eye(6ΔBU), Left eye(10ΔBI)

Solid suprachiasmatic cylinder ：

Jackson cross cylinder±0.50D , Axis fixation90°

Visual degree：

32°
